Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Compact 2.5G Cloud Gateway |
UCG-MAX | |||
|
Compact 2.5G Cloud Gateway with 30+ UniFi device / 300+ client support 1.5 Gbps IPS routing and selectable NVR storage. |
UCG-MAX | |||
|
UniFi Cloud Gateway Max - UCG-Max |
18012 | |||
|
UCG-MAX |
UBIUCGMAX | |||
|
UCG-MAX UniFi Cloud Gateway Max Compact 2.5 GBE Cloud Gateway Router |
NPUBI-UCGMAX | |||
|
- Gateway - 1GbE, 2.5GbE - cloud-managed - desktop |
W128911428 | |||
|
UniFi Cloud Gateway Max - UCG-Max |
UCG-max | |||
|
Cloud Gateway Max gateway/controller 10, |
UCG-MAX | |||
|
Router Ubiquiti UniFi Cloud Gateway Ul |
527481 | |||
|
UCG-MAX 2.5GB CLOUD GATEWAY |
93641 | |||
|
Gateway - 1GbE 2.5GbE - Cloud-verwaltet |
UCG-MAX | |||
|
UCG-MAX |
UBIUCGMAX | |||
|
Ubiquiti UniFi Cloud Gateway Max (1xWAN/4xLAN) UCG-MAX Powerful and compact multi-WAN UniFi Cloud Gateway |
3710169 | |||
|
Cloud Gateway Max gateway/controller 10, 100, 1000 Mbit/s |
UCG-MAX | |||
|
UniFi Cloud Gateway Max - White |
UCG-MAX |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
UCG-MAX UniFi Cloud Gateway Max Compact 2.5 GBE Cloud Gateway Router |
NPUBI-UCGMAX | |||
|
|
UCG-MAX 2.5GB CLOUD GATEWAY |
NS93641 | |||
Description
Specifications
| Design | |
|---|---|
| LED indicators | Activity, LAN |
| Certification | CE, FCC, IC |
| Product colour | White |
| Enclosure material | Polycarbonate (PC) |
| Performance | |
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Number of processors installed | 1 |
| Internal memory type | DDR4 |
| Internal memory | 3072 MB |
| Display type | LCM |
| Control display unit | Yes |
| Processor model | Cortex-A53 |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| SSD capacity | 512 GB |
| Certification | CE, FCC, IC |
| Product colour | White |
| Enclosure material | Polycarbonate (PC) |
| Protocols | |
| DHCP server | Yes |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Bluetooth | Yes |
| Security | |
| VLAN support | Yes |
| Firewall security | Yes |
| Ports & interfaces | |
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 4 |
| Management features | |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Power | |
| Output voltage | 5 V |
| Output current | 5 A |
| Input voltage | 100 - 240 V |
| Power consumption (max) | 16.1 W |
| Weight & dimensions | |
| Weight | 519 g |
| Width | 141.8 mm |
| Height | 30 mm |
| Depth | 127.6 mm |
| Packaging content | |
| Cables included | LAN (RJ-45) |
| Manual | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Number of processors installed | 1 |
| Manual | Yes |
| AC adapter included | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Indication | |
| LED indicators | Activity, LAN |
| Memory | |
| Internal memory type | DDR4 |
| Internal memory | 3072 MB |
| Display | |
| Display type | LCM |
| Control display unit | Yes |
| Certificates | |
| Certification | CE, FCC, IC |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Features | |
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Number of processors installed | 1 |
