StarTech.com USB DVI KVM Console Extender w/ Serial & Audio Over MM Fiber - 2km

StarTech.com USB DVI KVM Console Extender w/ Serial & Audio Over MM Fiber - 2km

  • Brand: StarTech.com
  • Category:
  • SKU: SV565FXDUSA
  • EAN: 0065030839426 0851975718410 01 ...5718410 0163121153090 0132017613314 0132017927824more
StarTech.com USB DVI KVM Console Extender w/ Serial & Audio Over MM Fiber - 2km - Fiber DVI KVM Extender

Trade Prices

Distributor Product SKU Stock Updated Price
Ingram Micro USB DVI KVM CONSOLE EXTENDER W/ V931090 Register free see stock
EET USB DVI KVM Console Ext w/ SV565FXDUSA
Ingram Micro CS USB DVI KVM CONSOLE EXTENDER W/ V931090

Retail Prices

Merchant Product Condition Updated Price
Amazon New £2,222.44

Description

Extend DVI-D (or HDMI) video, USB, audio, and Serial signals up to 2km (6562ft) over fiber

The SV565FXDUSA USB DVI KVM Console Extender w/ Serial & Audio Over MM Fiber (2km) lets you control a server, computer or multiple computers (connected through KVM Switch) over a multi-mode fiber link, at distances of up to 2000m (6562 ft) away.

By transmitting the digital DVI video (or HDMI with a DVI to HDMI adapter) over a multi-mode optical fiber link there is no loss of signal quality, so the video is as sharp and vivid as if the monitor was connected directly to the PC.

For added convenience, the Console/KVM extender supports USB computer connections, and is compatible with any brand of USB KVM Switch.

Backed by a StarTech.com 3-year warranty and free lifetime technical support.

The StarTech.com Advantage

- Ultimate connectivity by easily extending all connections in one unit (HD 1080p DVI or HDMI, USB K/B & Mouse, Serial, and Audio)
- Longest distance console extension at 100% quality over digital multimode fiber (2km / 6562 ft) without lag or video deterioration
- Perfectly secure transmissions over digital fiber cables make this ideal for any situation where data integrity is important

Specifications

Ports & interfaces
Number of microphone inputs4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
Headphone outputs4
Cable length2000 m
Technical details
Product colourBlack
Design
Product colourBlack
Cable length2000 m
CertificationCE, FCC, RoHS
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Weight1.03 kg
Package width125 mm
Package depth500 mm
Package height356 mm
Package weight5.8 kg
Packaging data
Package width125 mm
Package depth500 mm
Package height356 mm
Package weight5.8 kg
Certificates
CertificationCE, FCC, RoHS
Other features
Connectivity technologyWired
Power requirementsAC 110 - 240 V
Dimensions (WxDxH)220 x 135 x 44 mm
I/O ports8x 3.5 mm, F 4x 9 pin, DB-9, M 4x 24 pin, DVI-I, F 4x USB, Type A, F 2x USB, Type B, F 2x Fiber Optic SC, F
Logistics data
Harmonized System (HS) code85176200
