Lenovo ThinkSmart Edition Tiny M920q for Zoom Rooms with 3 Year Premier Support
- Brand: Lenovo
- Category:
- SKU: 10T10009UK
- EAN: 0194632648096
Intel Core i7-9700T (8C/8T, 2.0/4.3GHz, 12MB), 2x 8GB SO-DIMM DDR4-2666, 1x 128GB SSD M.2 2242 PCIe 3.0x2 NVMe, Intel UHD Graphics 630, Intel 9560 11ac 2x2 + BT5.0 vPro, Windows 10 IoT Enterprise
Offer details
Related Products
Description
Includes 3 Year Premier Support
Lenovo™ Premier Support provides direct access to skilled and experienced Lenovo technicians offering comprehensive hardware and software support. Our expert troubleshooters have the advanced technical know-how and systems knowledge to quickly provide solutions and advice that will keep your hardware and software operating at optimal efficiency.
Tech support with the Premier difference
- Advanced-level techs
- End to End case management
- Faster, first-time resolution
- Available 24 x 7 x 365
Lenovo Premier Support. Lenovo Premier Support is the premium PC support solution for your Think devices. With around-the-clock access to Lenovo engineers, you’ll have the expert hardware and software support needed to get the very most out of your PC.
Prioritized Parts & Labor. Premier Support means you receive front-of-the-queue, priority access when you need repairs.
Advanced Technical Support. Available 24 x 7 x 365, Premier Support gives you direct VIP access to elite Lenovo Premier Support engineers that are accessible via phone, chat, or email. Our highly trained Lenovo engineers are there to deliver faster, first time resolutions, and handle your case end to end until it’s resolved.
Comprehensive Hardware & Software Support. Lenovo Premier Support engineers provide complete hardware and software support. With comprehensive hardware, third-party software, and industry-standard applications knowledge, Premier Support delivers end to end support.
Lenovo™ Premier Support provides direct access to skilled and experienced Lenovo technicians offering comprehensive hardware and software support. Our expert troubleshooters have the advanced technical know-how and systems knowledge to quickly provide solutions and advice that will keep your hardware and software operating at optimal efficiency.
Tech support with the Premier difference
- Advanced-level techs
- End to End case management
- Faster, first-time resolution
- Available 24 x 7 x 365
Lenovo Premier Support. Lenovo Premier Support is the premium PC support solution for your Think devices. With around-the-clock access to Lenovo engineers, you’ll have the expert hardware and software support needed to get the very most out of your PC.
Prioritized Parts & Labor. Premier Support means you receive front-of-the-queue, priority access when you need repairs.
Advanced Technical Support. Available 24 x 7 x 365, Premier Support gives you direct VIP access to elite Lenovo Premier Support engineers that are accessible via phone, chat, or email. Our highly trained Lenovo engineers are there to deliver faster, first time resolutions, and handle your case end to end until it’s resolved.
Comprehensive Hardware & Software Support. Lenovo Premier Support engineers provide complete hardware and software support. With comprehensive hardware, third-party software, and industry-standard applications knowledge, Premier Support delivers end to end support.
Specifications
Processor | |
---|---|
Processor generation | 9th gen Intel® Core™ i7 |
Processor operating modes | 64-bit |
Processor lithography | 14 nm |
Processor codename | Coffee Lake |
Maximum internal memory supported by processor | 128 GB |
Memory types supported by processor | DDR4-SDRAM |
Memory clock speeds supported by processor | 2666 MHz |
Tjunction | 100 °C |
Thermal Design Power (TDP) | 35 W |
PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
Maximum number of PCI Express lanes | 16 |
Configurable TDP-down | 25 W |
Memory bandwidth supported by processor (max) | 41.6 GB/s |
Processor cache type | Smart Cache |
Configurable TDP-down frequency | 1.5 GHz |
Processor cache | 12 MB |
Processor frequency | 2 GHz |
Processor model | i7-9700T |
Number of processors installed | 1 |
Processor manufacturer | Intel |
Processor boost frequency | 4.3 GHz |
System bus rate | 8 GT/s |
Processor socket | LGA 1151 (Socket H4) |
Processor threads | 8 |
Processor cores | 8 |
PCI Express slots version | 3.0 |
Processor family | Intel® Core™ i7 |
Memory | |
Memory layout (slots x size) | 2 x 8 GB |
Internal memory | 16 GB |
Maximum internal memory | 32 GB |
Memory slots | 2x SO-DIMM |
Internal memory type | DDR4-SDRAM |
Memory clock speed | 2666 MHz |
Storage | |
Storage media | SSD |
Number of storage drives installed | 1 |
Optical drive type | No |
SSD interface | PCI Express |
SSD capacity | 128 GB |
Number of SSDs installed | 1 |
Card reader integrated | No |
Total storage capacity | 128 GB |
SSD form factor | M.2 |
Total SSDs capacity | 128 GB |
Graphics | |
Discrete graphics card | No |
On-board graphics card dynamic frequency (max) | 1200 MHz |
On-board graphics card base frequency | 350 MHz |
Maximum on-board graphics card memory | 64 GB |
Number of displays supported (on-board graphics) | 3 |
On-board graphics card OpenGL version | 4.5 |
On-board graphics card DirectX version | 12.0 |
On-board graphics card ID | 0x3E98 |
On-board graphics card | Yes |
Discrete graphics card model | Not available |
On-board graphics card model | Intel® UHD Graphics 630 |
On-board GPU manufacturer | Intel |
Optical drive | |
Optical drive type | No |
Network | |
Ethernet LAN | Yes |
Wi-Fi | Yes |
Bluetooth | Yes |
Bluetooth version | 5.0 |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Cabling technology | 10/100/1000Base-T(X) |
WLAN controller model | Intel Dual Band Wireless-AC 9560 |
Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
Antenna type | 2x2 |
WLAN controller manufacturer | Intel |
Ports & interfaces | |
Combo headphone/mic port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
Microphone in | Yes |
Headphone outputs | 1 |
HDMI ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 1 |
DVI port | No |
DisplayPorts quantity | 1 |
Expansion slots | |
PCI Express slots version | 3.0 |
Technical details | |
Intel 64 | Yes |
Cable lock slot type | Kensington |
Product type | Mini PC |
Trusted Platform Module (TPM) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Product colour | Black |
Chassis type | Mini PC |
Audio system | High Definition Audio |
Placement supported | Horizontal/Vertical |
Cable lock slot | Yes |
Motherboard chipset | Intel Q370 |
Sustainability certificates | ENERGY STAR |
Compliance certificates | RoHS |
Design | |
VESA mounting | Yes |
Volume | 1 L |
Cable lock slot type | Kensington |
Product colour | Black |
Chassis type | Mini PC |
Placement supported | Horizontal/Vertical |
Cable lock slot | Yes |
Colour name | Black |
Intel® vPro™ Platform Eligibility | Yes |
Performance | |
Embedded options available | No |
Audio chip | Realtek ALC233VB2 |
Number of speakers | 1 |
Password protection | Yes |
Product type | Mini PC |
Trusted Platform Module (TPM) | Yes |
Audio system | High Definition Audio |
Motherboard chipset | Intel Q370 |
Software | |
Operating system architecture | 64-bit |
Operating system installed | Windows 10 IoT Enterprise |
Processor special features | |
Embedded options available | No |
Enhanced Intel SpeedStep Technology | Yes |
Thermal Monitoring Technologies | Yes |
Intel® OS Guard | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel TSX-NI | Yes |
Intel Trusted Execution Technology | Yes |
Intel Stable Image Platform Program (SIPP) | Yes |
Intel® Secure Key | Yes |
Intel® InTru™ 3D Technology | Yes |
Intel Clear Video Technology | Yes |
Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Idle States | Yes |
Execute Disable Bit | Yes |
Intel Software Guard Extensions (Intel SGX) | Yes |
Thermal solution specification | PCG 2015A |
Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
Scalability | 1S |
Processor package size | 37.5 x 37.5 mm |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
CPU configuration (max) | 1 |
Intel Virtualization Technology (VT-x) | Yes |
Processor ARK ID | 191048 |
Intel 64 | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Yes |
Intel® Identity Protection Technology (Intel® IPT) | Yes |
Intel® Hyper Threading Technology (Intel® HT Technology) | No |
Intel® vPro™ Platform Eligibility | Yes |
Power | |
Power supply | 135 W |
Certificates | |
Certification | MIL-STD-810G |
Compliance certificates | RoHS |
Sustainability | |
Sustainability certificates | ENERGY STAR |
Ergonomics | |
VESA mounting | Yes |
Weight & dimensions | |
Volume | 1 L |
Width | 179 mm |
Depth | 182.9 mm |
Height | 34.5 mm |
Weight | 1.32 kg |
Packaging content | |
VESA mount included | Yes |
Mouse included | Yes |
Display included | No |
Keyboard included | Yes |
Other features | |
VESA mounting | Yes |
Number of speakers | 1 |
Trusted Platform Module (TPM) | Yes |
On-board graphics card | Yes |
Processor manufacturer | Intel |
