Lenovo ThinkPad Thunderbolt 4 WorkStation Wired Black, Red

Lenovo ThinkPad Thunderbolt 4 WorkStation Wired Black, Red

ThinkPad Thunderbolt 4 Workstation Dock

Trade Prices

Distributor Product SKU Stock Updated Price
Ingram Micro THINKPAD THUNDERBOLT 4 CB72430 Register free see stock
EET Thinkpad Thunderbolt 4 40B00300CH
Ingram Micro CS THINKPAD THUNDERBOLT 4 CB72430

Related Products

Description

Premium Thunderbolt™ 4 Docking Experience: ThinkPad Thunderbolt 4 Workstation Dock delivers reliable and consistent industry leading video, data and power connectivity; Maximize Your Productivity: Expand your horizon with versatile 8K display support or multiple 4K displays support, Upto 230W Power Delivery to Workstation, silent firmware upgrades, VPro/AMT support and transfer data at lightning fast 40Gbps.; The ThinkPad Thunderbolt 4 Workstation Dock is future-proof and fully loaded to take your productivity, efficiency and creativity to the peak.

Specifications

Ports & interfaces
Combo headphone/mic portYes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity4
Host interfaceThunderbolt 4
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
HDMI version2.1
DisplayPorts quantity2
Microphone inNo
Headphone outputs0
DC-in jackYes
Connectivity technologyWired
USB Power Delivery (USB PD)Yes
USB Power Delivery up to230 W
DisplayPort version1.4
Thunderbolt 4 ports quantity1
Network
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports1
Performance
Maximum digital resolution7680 x 4320 pixels
Number of displays supported4
Product colourBlack, Red
Card reader integratedNo
Built-in speaker(s)No
Cable lock slotYes
LED indicatorsYes
Data transfer rate40 Gbit/s
CertificationcULus, FCC, ICES, NOM
Cable lock slot typeKensington
HD type8K Ultra HD
VESA mountingYes
Maximum refresh rate30 Hz
Audio
Built-in speaker(s)No
Technical details
Product colourBlack, Red
Cable lock slotYes
Data transfer rate40 Gbit/s
Harmonized System (HS) code84733020
Storage
Card reader integratedNo
Multimedia
Built-in speaker(s)No
Power
Power source typeAC
Power consumption (max)230 W
Output voltage20 V
Output current15 A
Power supply300 W
Software
Windows operating systems supportedWindows 10
Indication
LED indicatorsYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95%
Weight & dimensions
Weight450 g
Width220 mm
Depth80 mm
Height30 mm
Package weight1.9 kg
Package width270 mm
Package depth195 mm
Package height85 mm
Design
Windows operating systems supportedWindows 10
Product colourBlack, Red
Cable lock slotYes
LED indicatorsYes
CertificationcULus, FCC, ICES, NOM
Cable lock slot typeKensington
Packaging data
Quantity per pack1 pc(s)
Package weight1.9 kg
Package width270 mm
Package depth195 mm
Package height85 mm
Packaging content
ManualYes
Cables includedAC
AC adapter includedYes
Warranty cardYes
Quantity per pack1 pc(s)
Certificates
CertificationcULus, FCC, ICES, NOM
Logistics data
Harmonized System (HS) code84733020
