Ports & interfaces |
---|
I/O ports | 4 open module slots; 96 auto-sensing 10/100 ports(IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX), Media Type: Auto-MDIX, Duplex: half or full; Supports a maximum of 192 auto-sensing 10/100 ports or 96 auto-sensing 10/100/1000 ports or 16 mini-GBICs or 4 10-GbE ports, or a combination |
Basic switching RJ-45 Ethernet ports quantity | 96 |
Console port | RS-232 |
Network |
---|
IGMP snooping | Yes |
Full duplex | Yes |
Spanning tree protocol | Yes |
Link aggregation | Yes |
Flow control support | Yes |
Auto MDI/MDI-X | Yes |
Performance |
---|
Packet buffer memory | 36 MB |
Stackable | Yes |
Processor frequency | 330 MHz |
Memory type | SDRAM |
Internal memory | 64 MB |
Flash memory | 24 MB |
Built-in processor | Yes |
Processor model | PowerPC MPC8245 |
Weight & dimensions |
---|
Weight (imperial) | Fully loaded
32.3 lb. |
Weight | 14.7 kg |
Power |
---|
Power supply slots open | 1 |
Power consumption (typical) | 630 W |
Input voltage | 100-127 / 200-240 VAC |
Input current | 3.8 - 8.2 A |
Power source | 1 x J4839A |
Technical details |
---|
Stackable | Yes |
Processor frequency | 330 MHz |
Switch fabric speed | 76.8 Gbps |
Supported protocols | General protocols
HTML and telnet management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP); RFC 1757 RMON 4 groups: Stats, History, Alarms and Events; RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3164 BSD syslog Protocol; RFC 3176 sFlow; ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED); SNMPv1/v2c/v3; XRMON
Network management
MIBs
Device management
IP multicast
IEEE 802.1D MAC Bridges; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1s Multiple Spanning Trees; IEEE 802.1w Rapid Reconfiguration of Spanning Tree; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3x Flow Control; RFC 768 UDP; RFC 783 TFTP Protocol (revision 2); RFC 791 IP; RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 854 TELNET; RFC 1542 BOOTP Extensions; RFC 2030 Simple Network Time Protocol (SNTP) v4; RFC 3046 DHCP Relay Agent Information Option
Security
RFC 1213 MIB II; RFC 1493 Bridge MIB; RFC 2613 SMON MIB; RFC 2618 RADIUS Client MIB; RFC 2665 Ethernet-Like-MIB; RFC 2668 802.3 MAU MIB; RFC 2737 Entity MIB (Version 2)
QoS/Cos
RFC 2474 DiffServ Precedence, including 8 queues/port; RFC 2597 DiffServ Assured Forwarding (AF); RFC 2598 DiffServ Expedited Forwarding (EF)
IEEE 802.1X Port Based Network Access Control; RFC 2138 RADIUS Authentication; Secure Sockets Layer (SSL); SSHv2 Secure Shell
RFC 3376 IGMPv3 |
Operating altitude (imperial) | up to 15000 ft. |
Management product name | HP ProCurve Manager Plus; HP ProCurve Manager (included) |
Electromagnetic immunity | EN 55024, CISPR 24; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2, IEC 61000-3-2; EN 61000-3-3, IEC 61000-3-3 |
Built-in processor | Yes |
Management features |
---|
Switch type | Managed |
MIB support | Repeater MIB; Ethernet Interface MIB; IEEE 802.3 Ethernet MIB |
Data transmission |
---|
Throughput | up to 48 million pps |
Packet buffer memory | 36 MB |
Switching capacity | 76.8 Gbit/s |
Maximum data transfer rate | 0.1 Gbit/s |
Security |
---|
SSH/SSL support | Yes |
IGMP snooping | Yes |
Protocols |
---|
Supported network protocols | RFC 783 TFTP; RFC 1542 BootP; RFC 768 UDP; RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 2030 SNTP; RFC 2030 Simple Network Time Protocol; IEEE 802.3x Flow Control; DHCP Relay; RFC 3046 DHCP Relay Agent Information Option 82; RFC 3376 IGMPv1/v2/v3; IEEE 802.1D Spanning Tree; IEEE 802.1w Rapid Convergence Spanning Tree; IEEE 802.1s Multiple Spanning Trees; IEEE 802.3ad Link Aggregation Control Protocol; IEEE 802.1AB Link Layer Discovery Protocol; ANSI/TIA-1057 LLDP Media Endpoint Discovery (MED); RFC 2474 DiffServ Precedence; RFC 2598 DiffServ Expedited Forwarding (EF); RFC 2597 DiffServ Assured Forwarding (AF); RFC 2138 RADIUS; SSHv2 Secure Shell; Secure Sockets Layer (SSL); IEEE 802.1X Network Login; IEEE 802.1Q VLAN tagging; IEEE 802.1Q GVRP; IEEE 802.1p Priority; SNMPv1/v2c/v3; RFC 1493 Bridge MIB; RFC 1213 MIB II; RFC 2737 Entity MIB; RFC 2665 Ethernet MIB; RFC 2668 802.3 MAU MIB; RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3164 Syslog; XRMON; RFC 2613 SMON; RFC 2618 RADIUS Client MIB; RFC 791 IP; RFC 1757 RMON Groups 1,2,3,9; RFC 3176 sFlow |
Supported protocols | General protocols
HTML and telnet management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP); RFC 1757 RMON 4 groups: Stats, History, Alarms and Events; RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3164 BSD syslog Protocol; RFC 3176 sFlow; ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED); SNMPv1/v2c/v3; XRMON
Network management
MIBs
Device management
IP multicast
IEEE 802.1D MAC Bridges; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1s Multiple Spanning Trees; IEEE 802.1w Rapid Reconfiguration of Spanning Tree; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3x Flow Control; RFC 768 UDP; RFC 783 TFTP Protocol (revision 2); RFC 791 IP; RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 854 TELNET; RFC 1542 BOOTP Extensions; RFC 2030 Simple Network Time Protocol (SNTP) v4; RFC 3046 DHCP Relay Agent Information Option
Security
RFC 1213 MIB II; RFC 1493 Bridge MIB; RFC 2613 SMON MIB; RFC 2618 RADIUS Client MIB; RFC 2665 Ethernet-Like-MIB; RFC 2668 802.3 MAU MIB; RFC 2737 Entity MIB (Version 2)
QoS/Cos
RFC 2474 DiffServ Precedence, including 8 queues/port; RFC 2597 DiffServ Assured Forwarding (AF); RFC 2598 DiffServ Expedited Forwarding (EF)
IEEE 802.1X Port Based Network Access Control; RFC 2138 RADIUS Authentication; Secure Sockets Layer (SSL); SSHv2 Secure Shell
RFC 3376 IGMPv3 |
Certificates |
---|
Safety | CSA 22.2 No. 950; UL 60950; EN 60950 |
Electromagnetic compatibility | FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; CISPR 22 Class A; EN 55024; IEC/EN 61000-3-2; IEC/EN 61000-3-3 |
Electromagnetic emissions | FCC Class A; VCCI Class A; EN55022/CISPR-22 Class A; CISPR22 Class A; EN55024; IEC/EN61000-3-2; IEC/EN61000-3-3 |
Memory |
---|
Packet buffer memory | 36 MB |
Memory type | SDRAM |
Internal memory | 64 MB |
Flash memory | 24 MB |
Design |
---|
Safety | CSA 22.2 No. 950; UL 60950; EN 60950 |
Stackable | Yes |
Electromagnetic compatibility | FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; CISPR 22 Class A; EN 55024; IEC/EN 61000-3-2; IEC/EN 61000-3-3 |
Power over Ethernet (PoE) |
---|
Power over Ethernet (PoE) | No |
Operational conditions |
---|
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 32 - 104 °F |
Operating temperature (T-T) | 0 - 40 °C |
Other features |
---|
Management platform | HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (DB-9 serial port console); IEEE 802.3 Ethernet MIB; Repeater MIB; Ethernet Interface MIB |
Latency | Latency: < 6 µs (FIFO) |
Dimensions (WxDxH) | 388.6 x 442 x 222.3 mm |
Connectivity technology | Wired |
Remote administration | command-line interface; Web browser; configuration menu; out-of-band management (DB-9 serial port console) |
Power requirements | 100-127 VAC/200-240 VAC; 50/60 Hz |
Mounting | Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only. |
Memory and processor | Fabric: Motorola PowerPC MPC8245 @ 330 MHz, 24 MB flash, packet buffer size: 36 MB, 64 MB SDRAM |
Input voltage | 100-127 / 200-240 VAC |
Input frequency | 50 / 60 Hz |
Weight (imperial) | Fully loaded
32.3 lb. |
Switch fabric speed | 76.8 Gbps |
Power supply slots open | 1 |
Operating altitude (imperial) | up to 15000 ft. |
Management product name | HP ProCurve Manager Plus; HP ProCurve Manager (included) |
I/O ports | 4 open module slots; 96 auto-sensing 10/100 ports(IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX), Media Type: Auto-MDIX, Duplex: half or full; Supports a maximum of 192 auto-sensing 10/100 ports or 96 auto-sensing 10/100/1000 ports or 16 mini-GBICs or 4 10-GbE ports, or a combination |
Electromagnetic immunity | EN 55024, CISPR 24; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2, IEC 61000-3-2; EN 61000-3-3, IEC 61000-3-3 |
Electromagnetic emissions | FCC Class A; VCCI Class A; EN55022/CISPR-22 Class A; CISPR22 Class A; EN55024; IEC/EN61000-3-2; IEC/EN61000-3-3 |
Supported protocols | General protocols
HTML and telnet management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP); RFC 1757 RMON 4 groups: Stats, History, Alarms and Events; RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events); RFC 3164 BSD syslog Protocol; RFC 3176 sFlow; ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED); SNMPv1/v2c/v3; XRMON
Network management
MIBs
Device management
IP multicast
IEEE 802.1D MAC Bridges; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1s Multiple Spanning Trees; IEEE 802.1w Rapid Reconfiguration of Spanning Tree; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3x Flow Control; RFC 768 UDP; RFC 783 TFTP Protocol (revision 2); RFC 791 IP; RFC 792 ICMP; RFC 793 TCP; RFC 826 ARP; RFC 854 TELNET; RFC 1542 BOOTP Extensions; RFC 2030 Simple Network Time Protocol (SNTP) v4; RFC 3046 DHCP Relay Agent Information Option
Security
RFC 1213 MIB II; RFC 1493 Bridge MIB; RFC 2613 SMON MIB; RFC 2618 RADIUS Client MIB; RFC 2665 Ethernet-Like-MIB; RFC 2668 802.3 MAU MIB; RFC 2737 Entity MIB (Version 2)
QoS/Cos
RFC 2474 DiffServ Precedence, including 8 queues/port; RFC 2597 DiffServ Assured Forwarding (AF); RFC 2598 DiffServ Expedited Forwarding (EF)
IEEE 802.1X Port Based Network Access Control; RFC 2138 RADIUS Authentication; Secure Sockets Layer (SSL); SSHv2 Secure Shell
RFC 3376 IGMPv3 |
