Ernitec 0070-24222-AC computer monitor 55.9 cm (22") 1920 x 1080 pixels Full HD LED Black
- Brand: Ernitec
- Category:
- SKU: 0070-24222-AC
- EAN: 5715063068212
22'' Full-HD Surveillance monitor for 24/7 use
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
22 inch Surveillance monitor | 0070-24222-AC | |||
|
22 inch Surveillance monitor | W128325396 | |||
|
22 inch Surveillance monitor | 0070-24222-AC | |||
|
0070-24222-AC computer monitor 55.9 cm (22") 1920 x 1080 pixels Full HD LED Black | 0070-24222-AC |
Related Products
-
Category: Monitor Mounts & Stands -
Category: Monitor Mounts & Stands -
Category: Monitor Mounts & Stands -
Category: Monitor Mounts & Stands
Description
High Performance 24/7 Security Monitor
When you need a display that lasts, Ernitec delivers with this state-of-the-art monitor. Featuring a BNC input, it’s easy to connect your analog camera for seamless integration.
Display Characteristics
•Screen Size: 22 inches
•Active Display Area: 476.64mm (W) × 268.11mm (H)
•Display Mode: 16:9
•LED Type: TFT-LED
•Resolution: 1920 × 1080
•Display Color: 16.7 million
•Pixel Pitch: 0.248mm (H) × 0.248mm (V)
•Brightness: 250 nits
•Contrast Ratio: 1000:1
•Viewing Angle: 178° (H) / 178° (V)
•Response Time: 5ms
•Backlight: LED
Input & Output
•HDMI 2.0: 1
•VGA: 1
•BNC Input: 2
•BNC Output: 1
•Speaker: 2x 3W (Stereo)
Video
•Color System: PAL/NTSC/SECAM
•OSD Control: Auto adjust, Brightness, Contrast, Horizontal/Vertical Position, Clock, Phase, Color, Language
•3D Comb Filter: Yes
•Video Noise Reduction: Yes
Power & Mounting
•Power Supply: DC 12V, 50/60Hz
•Working Temperature: -30 to +85°C
•Power Consumption: ≤25W
•Menu Languages: English, French
•Mounting Options: Stand mount, VESA mount
•Weight: 3.5kg
•MTBF: 50,000 hours
•VESA Size: 100x100
•EDID Compatibility: Not compatible
Included Accessories
•Screws
•Cable holder
•Quick start guide
This monitor is designed to provide reliable performance around the clock, making it an ideal choice for security applications.
When you need a display that lasts, Ernitec delivers with this state-of-the-art monitor. Featuring a BNC input, it’s easy to connect your analog camera for seamless integration.
Display Characteristics
•Screen Size: 22 inches
•Active Display Area: 476.64mm (W) × 268.11mm (H)
•Display Mode: 16:9
•LED Type: TFT-LED
•Resolution: 1920 × 1080
•Display Color: 16.7 million
•Pixel Pitch: 0.248mm (H) × 0.248mm (V)
•Brightness: 250 nits
•Contrast Ratio: 1000:1
•Viewing Angle: 178° (H) / 178° (V)
•Response Time: 5ms
•Backlight: LED
Input & Output
•HDMI 2.0: 1
•VGA: 1
•BNC Input: 2
•BNC Output: 1
•Speaker: 2x 3W (Stereo)
Video
•Color System: PAL/NTSC/SECAM
•OSD Control: Auto adjust, Brightness, Contrast, Horizontal/Vertical Position, Clock, Phase, Color, Language
•3D Comb Filter: Yes
•Video Noise Reduction: Yes
Power & Mounting
•Power Supply: DC 12V, 50/60Hz
•Working Temperature: -30 to +85°C
•Power Consumption: ≤25W
•Menu Languages: English, French
•Mounting Options: Stand mount, VESA mount
•Weight: 3.5kg
•MTBF: 50,000 hours
•VESA Size: 100x100
•EDID Compatibility: Not compatible
Included Accessories
•Screws
•Cable holder
•Quick start guide
This monitor is designed to provide reliable performance around the clock, making it an ideal choice for security applications.
Specifications
| Audio | |
|---|---|
| Built-in speaker(s) | Yes |
| RMS rated power | 6 W |
| Performance | |
| Built-in speaker(s) | Yes |
| RMS rated power | 6 W |
| Mean time between failures (MTBF) | 50000 h |
| Display | |
| Display brightness (typical) | 250 cd/m² |
| Screen shape | Flat |
| Native aspect ratio | 16:9 |
| HD type | Full HD |
| Display technology | LED |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Viewable size, horizontal | 47.7 cm |
| Viewable size, vertical | 26.8 cm |
| Display resolution | 1920 x 1080 pixels |
| Response time | 5 ms |
| Display diagonal | 55.9 cm (22") |
| Contrast ratio (typical) | 10000:1 |
| Touchscreen | No |
| Panel type | TFT |
| Display diagonal (metric) | 55 cm |
| Multimedia | |
| Number of speakers | 2 |
| Built-in speaker(s) | Yes |
| RMS rated power | 6 W |
| Design | |
| Market positioning | Industrial |
| Product colour | Black |
| Mean time between failures (MTBF) | 50000 h |
| Ports & interfaces | |
| USB Type-A downstream ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| Audio input | Yes |
| Audio output | Yes |
| HDMI | Yes |
| BNC input ports | 1 |
| HDMI version | 2.0 |
| Technical details | |
| Mean time between failures (MTBF) | 50000 h |
| HDMI | Yes |
| Product colour | Black |
| Picture enhancement | DNIe digital image processing |
| Speakers | 2 x 3W Stereo |
| Comb filter | 3D |
| Touchscreen | No |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Power | |
| Power consumption (average) | 25 W |
| Energy efficiency class (SDR) | D |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 11 kWh |
| European Product Registry for Energy Labelling (EPREL) code | 1427684 |
| Packaging data | |
| Package width | 420 mm |
| Package depth | 110 mm |
| Package height | 550 mm |
| Package weight | 3.5 kg |
| Stand included | Yes |
| Quick start guide | Yes |
| Cables included | Power |
| Power adapter included | Yes |
| Screws included | Yes |
| Packaging content | |
| Stand included | Yes |
| Quick start guide | Yes |
| Cables included | Power |
| Power adapter included | Yes |
| Screws included | Yes |
| Sustainability | |
| European Product Registry for Energy Labelling (EPREL) code | 1427684 |
| Weight & dimensions | |
| Package width | 420 mm |
| Package depth | 110 mm |
| Package height | 550 mm |
| Package weight | 3.5 kg |
| Width | 310 mm |
| Weight | 2.5 kg |
| Height | 580 mm |
| Depth | 48 mm |
| Other features | |
| Speakers | 2 x 3W Stereo |
| Comb filter | 3D |
| Mean time between failures (MTBF) | 50000 h |
| Picture enhancement | DNIe digital image processing |
| Width | 310 mm |
| Weight | 2.5 kg |
| Height | 580 mm |
| Depth | 48 mm |
| Quick start guide | Yes |
| HDMI | Yes |
| Touchscreen | No |
