Digitus Gigabit PoE media converter, RJ45 / SC, MM, PSE
- Brand: Digitus
- Category:
- SKU: DN-82150
- EAN: 4016032390022
Gigabit Ethernet PoE+ Media Converter, Multimode 802.3at, 30W, SC connector, up to 0.5km
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Gigabit Ethernet PoE+ Media Converter, Multimode |
DN-82150 | |||
|
Professional DN-82150 - medieo |
276585 |
| Alternative Suppliers | |||||
|---|---|---|---|---|---|
|
EU Product - Gigabit PoE media converter RJ45 / SC MM PSE |
DN-82150 | |||
Retail Prices
| Merchant | Product | Condition | Updated | Price |
|---|---|---|---|---|
| Amazon | New | £82.91 | ||
| Amazon | New | £76.90 |
Description
The perfect converter solution for optical data transmission
- PoE power supplier, PSE
- Sends data with high quality and additionally offers the highest level of failure safety
- A fast transfer in the gigabit range is guaranteed
- Range of up to 0.5km
The media converters from DIGITUS® are an optimal solution for the migration of copper and fiber optic signals. From now on, you can access the fiber optic technology and transmit fiber optic signals over several kilometers without having to replace your entire network cabling. With our comprehensive range of products, you can respond to your individual needs. The intuitive operation guarantees a quick and easy installation. Many years of experience and a diverse range of services make DIGITUS® a reliable partner for your network technology.
- PoE power supplier, PSE
- Sends data with high quality and additionally offers the highest level of failure safety
- A fast transfer in the gigabit range is guaranteed
- Range of up to 0.5km
The media converters from DIGITUS® are an optimal solution for the migration of copper and fiber optic signals. From now on, you can access the fiber optic technology and transmit fiber optic signals over several kilometers without having to replace your entire network cabling. With our comprehensive range of products, you can respond to your individual needs. The intuitive operation guarantees a quick and easy installation. Many years of experience and a diverse range of services make DIGITUS® a reliable partner for your network technology.
Specifications
| Network | |
|---|---|
| Data transfer rate | 1000 Mbit/s |
| Copper ethernet cabling technology | 100BASE-TX, 1000BASE-TX |
| Fiber ethernet cabling technology | 1000BASE‑SX |
| Converter input interface | 100Base-TX, 1000Base-TX |
| Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Duplex system | Full, Half |
| Converter output interface | 1000Base-SX |
| Auto MDI/MDI-X | Yes |
| Maximum data transfer rate | 1000 Mbit/s |
| Fiber optic connector | SC |
| Performance | |
| Wavelength | 850 nm |
| Maximum transfer distance | 500 m |
| Fiber mode structure | Multi-mode |
| Mean time between failures (MTBF) | 500000 h |
| Features | |
| LED indicators | Activity, Link, Power, Status |
| Product colour | Black |
| Internal | No |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SC |
| DC-in jack | Yes |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 30 W |
| Input voltage | 5 V |
| Output voltage | 48 - 52 V |
| External power adapter | Yes |
| Weight & dimensions | |
| Width | 71 mm |
| Depth | 95 mm |
| Height | 26 mm |
| Package volume | 1872 cm³ |
| Package depth | 240 mm |
| Package width | 130 mm |
| Package height | 60 mm |
| Package weight | 800 g |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 65 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Packaging content | |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Packaging data | |
| Package volume | 1872 cm³ |
| Package depth | 240 mm |
| Package width | 130 mm |
| Package height | 60 mm |
| Package weight | 800 g |
| Technical details | |
| Wavelength | 850 nm |
| Maximum transfer distance | 500 m |
| Fiber mode structure | Multi-mode |
| Internal | No |
| Data transfer rate | 1000 Mbit/s |
| Harmonized System (HS) code | 85176990 |
| Indication | |
| LED indicators | Activity, Link, Power, Status |
| Design | |
| Country of origin | China |
| LED indicators | Activity, Link, Power, Status |
| Product colour | Black |
| Internal | No |
| Endurance | |
| Mean time between failures (MTBF) | 500000 h |
| Colour | |
| Product colour | Black |
| Logistics data | |
| Country of origin | China |
| Master (outer) case width | 410 mm |
| Master (outer) case length | 570 mm |
| Master (outer) case height | 280 mm |
| Master (outer) case gross weight | 8 kg |
| Master (outer) case volume | 65436 cm³ |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 85176990 |
| UK Trade Tariff code | 85176200 |
