Blustream HMXL88ARC AV receiver Black
- Brand: BLUSTREAM
- Category:
- SKU: HMXL88ARC
- EAN: 9340242003676
HDMI, HDBaseT, RJ45 connector, Audio In/Audio Out, RS-232 Serial Ports, IR In/IR Out, black
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
8x8 HDBaseT™ CSC AV Matrix - 70m (4K60Hz 4:4:4 up to 40m), ARC, Bi-directional IR, RS-232, PoC, Simultaneous HDMI / HDBaseT™ on output 1, video Smart Scaling on HDBaseT outputs, Independent Audio Matrix, Line Level Volume Control, RS-232 & TCP/IP Control, |
HMXL88ARC |
Description
8x8 HDBaseT CSC ARC Matrix - 70m
The HMXL88ARC HDBaseT Matrix delivers new levels of advanced audio integration into our Essential range of 4K video matrix solutions. The HMXL88ARC is an 8x8 HDMI 2.0 4K 60Hz 4:4:4 matrix that uses CSC (Colour Space Conversion) technology to deliver 18Gbps HDMI over distances of up to 40m (1080p to 70m).
The HMXL88ARC features enhanced audio routing via an integrated 26x8 audio matrix. This enables the audio both from displays and sources, to be embedded and routed through the system at the users discretion.
The HMXL88ARC includes a simultaneous HDBaseT™ / HDMI output on output 1, video smart scaling on all HDBaseT™ outputs, and PoC (Power over Cable) to the remote RX70CS HDBaseT™ receivers. A in-built web browser interface for configuration and control of the Matrix, along with RS-232 and IR pass-through to enable seamless 3rd party control integration.
The HMXL88ARC HDBaseT Matrix delivers new levels of advanced audio integration into our Essential range of 4K video matrix solutions. The HMXL88ARC is an 8x8 HDMI 2.0 4K 60Hz 4:4:4 matrix that uses CSC (Colour Space Conversion) technology to deliver 18Gbps HDMI over distances of up to 40m (1080p to 70m).
The HMXL88ARC features enhanced audio routing via an integrated 26x8 audio matrix. This enables the audio both from displays and sources, to be embedded and routed through the system at the users discretion.
The HMXL88ARC includes a simultaneous HDBaseT™ / HDMI output on output 1, video smart scaling on all HDBaseT™ outputs, and PoC (Power over Cable) to the remote RX70CS HDBaseT™ receivers. A in-built web browser interface for configuration and control of the Matrix, along with RS-232 and IR pass-through to enable seamless 3rd party control integration.
Specifications
| Inputs | |
|---|---|
| USB ports quantity | 0 |
| HDMI in | 8 |
| Audio (L/R) in | 1 |
| Remote (IR) input | 9 |
| Ethernet LAN (RJ-45) ports | 8 |
| Outputs | |
| Number of HDMI outputs | 1 |
| Audio (L/R) out | 8 |
| Remote (IR) output | 9 |
| Ports & interfaces | |
| Speakers connectivity type | 3.5mm |
| RS-232 ports | 9 |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Radio | |
| Supported radio bands | Not supported |
| Optical drive | |
| Optical drive included | No |
| Storage | |
| Card reader integrated | No |
| Video | |
| 3D | No |
| Technical details | |
| Audio decoders | DTS-HD Master Audio, Dolby Atmos, Dolby Digital Plus, Dolby TrueHD |
| Remote control included | Yes |
| Product colour | Black |
| AirPlay | No |
| Power | |
| AC input voltage | 100-240 V |
| Weight & dimensions | |
| Width | 436 mm |
| Depth | 400 mm |
| Height | 88 mm |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 55 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Packaging data | |
| Package weight | 10.5 kg |
| Packaging content | |
| User guide | Yes |
