ATEN 8-Port 17.3" DVI Full HD LCD KVM Switch (USB)
- Brand: ATEN
- Category:
- SKU: CL6708MW
- EAN: 4719264643804 0672792006845
8-Port USB DVI Single Rail WideScreen LCD KVM Switch
Offer details
Retail Prices
Merchant | Product | Condition | Updated | Price |
---|---|---|---|---|
Amazon | New | £1,697.46 |
Related Products
Description
The CL6708MW brings additional versatility to ATEN’s line of LCD KVM Switches with its native DVI compatibility. Building on ATEN’s renowned, space-saving approach to KVM switches – which integrates an LCD panel, full keyboard, and touchpad into a streamlined, 1U housing – the CL6708MW is a highly-scalable LCD KVM switch which features the ability to control up to 64 computers by cascading 8 additional CS1768 8-port KVM switches.
Featuring an integrated 17.3" LED-backlit LCD panel capable of full HD 1080p video – greater clarity than typical analog interfaces – the CL6708MW incorporates the YUV video format for greater compatibility with high-definition signals (e.g. NVR sources). Similarly, the CL6708MW is High-Bandwidth Digital Content Protection (HDCP) compatible, making it well-suited for use with content-protected media in corporate, educational, and commercial settings.
To further enhance usability, ATEN’s LED illumination light is included to ensure keyboard and touchpad visibility in low-light conditions.
Note: Optional rack mount kits are available. For more information, refer to Compatible Accessories below.
Featuring an integrated 17.3" LED-backlit LCD panel capable of full HD 1080p video – greater clarity than typical analog interfaces – the CL6708MW incorporates the YUV video format for greater compatibility with high-definition signals (e.g. NVR sources). Similarly, the CL6708MW is High-Bandwidth Digital Content Protection (HDCP) compatible, making it well-suited for use with content-protected media in corporate, educational, and commercial settings.
To further enhance usability, ATEN’s LED illumination light is included to ensure keyboard and touchpad visibility in low-light conditions.
Note: Optional rack mount kits are available. For more information, refer to Compatible Accessories below.
Specifications
Ports & interfaces | |
---|---|
Console USB ports quantity | 2 |
Console ports | 3.5mm headphone, DVI-I, USB A |
USB connector type | USB Type-A |
Number of computers controlled | 64 |
Keyboard port type | USB |
Mouse port type | USB |
Video port type | DVI-I |
Audio connections | Yes |
Headphone outputs | 8 |
DVI-I ports quantity | 9 |
HDCP | Yes |
Performance | |
DDC2B support | Yes |
HDCP | Yes |
Firmware upgradeable | Yes |
HD type | Full HD |
Video bandwidth | 60 Hz |
Maximum resolution | 1920 x 1080 pixels |
Scan interval | 1,255 s |
Technical details | |
Product colour | Black |
Rack mounting | Yes |
Scan interval | 1,255 s |
Push button | Yes |
On Screen Display (OSD) | Yes |
LED indicators | Yes |
Hot keys | Yes |
Compliance certificates | RoHS |
Design | |
Product colour | Black |
Rack mounting | Yes |
Push button | Yes |
LED indicators | Yes |
Hot keys | Yes |
Rack capacity | 1U |
Housing material | Metal, Plastic |
Display | |
Built-in display | Yes |
Display | LCD |
On Screen Display (OSD) | Yes |
Display diagonal | 43.9 cm (17.3") |
Power | |
Input current | 1 A |
Power source | AC |
AC input frequency | 50 - 60 Hz |
Power consumption (typical) | 29.26 W |
Input voltage | 100-240 V |
System requirements | |
Windows operating systems supported | Yes |
Linux operating systems supported | Yes |
Mac operating systems supported | Yes |
Other operating systems supported | Yes |
Video | |
HD type | Full HD |
Video bandwidth | 60 Hz |
Maximum resolution | 1920 x 1080 pixels |
Sustainability | |
Compliance certificates | RoHS |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 60 °C |
Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions | |
Width | 480 mm |
Depth | 689.2 mm |
Height | 44 mm |
Weight | 12.7 kg |
Packaging content | |
Rack mount kit | Yes |
Cables included | AC, KVM |
Manual | Yes |
AC adapter included | Yes |
Other features | |
Push button | Yes |
Hot keys | Yes |
