Offer details
Trade Prices
Distributor | Product | SKU | Stock | Updated | Price |
---|---|---|---|---|---|
Symmetra LX 16kVA Scalable- 16kVA RM | 000000000000106675 | ||||
SYMMETRA LX 16KVA | 10000217 | ||||
SYMMETRA LX 16KVA RACKMNT | 2702322 | ||||
Symmetra LX 16kVA Scalable to 16kVA N+1 Rack-mount, 220/230/240V or 380/400/415V | SYA16K16RMI | ||||
Freight charge of 1% to be added for APC kit, Please add SKU 2550388 at 1% of total order value to your PO when placing order | 925584 | ||||
Symmetra LX/16KVA on-line | SYA16K16RMI | ||||
Ingram Micro CS | SYMMETRA LX 16KVA RACKMNT | 2702322 |
Description
High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.
Specifications
Power | |
---|---|
Output power | 11200 W |
Emergency Power Off (EPO) | Yes |
Output power capacity | 16 kVA |
Battery | |
Battery type | Lead-Acid |
Typical backup time at half load | 20.3 min |
Typical backup time at full load | 7.5 min |
Replacement battery cartridge | SYBT5 |
Performance | |
Audible alarm(s) | Yes |
Features | |
Output power | 11200 W |
Emergency Power Off (EPO) | Yes |
Audible alarm(s) | Yes |
Output power capacity | 16 kVA |
Compatibility | C-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE |
Design | |
Compatibility | C-tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Technical details | |
Harmonized System (HS) code | 85078000 |
Packaging data | |
Package dimensions (WxDxH) | 599 x 997 x 1054 mm |
Package weight | 340.4 kg |
Weight & dimensions | |
Weight | 286.8 kg |
Package weight | 340.4 kg |
Logistics data | |
Harmonized System (HS) code | 85078000 |
Other features | |
Interface | DB-9 RS-232, Smart-Slot |
Battery type | Lead-Acid |
Output connections | (1) Hard Wire 3-wire (H N + G) (8) IEC 320 C13 (10) IEC 320 C19 |
Input connection type | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
Dimensions (WxDxH) | 472 x 688 x 838 mm |
Package dimensions (WxDxH) | 599 x 997 x 1054 mm |
Output voltage note | 220: 230, 240 |
Nominal input voltage | 230 V |
I/O ports | (1) Hard Wire 3-wire (H N + G) (8) IEC 320 C13 (10) IEC 320 C19 Hard Wire 3 wire (1PH+N+G) Hard Wire 5-wire (3PH + N + G) |
