APC Easy Rack PDU, Basic, 1U, 1 Phase, 2.3kW, 230V, 10A, 6 SCHUKO and 1 C13 outlets, IEC60320 C14 inlet

Easy Rack PDU, Basic, 1U, 1 Phase, 2.3kW, 230V, 10A, 6 SCHUKO and 1 C13 outlets, IEC60320 C14 inlet

Trade Prices

Distributor Product SKU Stock Updated Price
Exertis IT EasyPDU Basic 1U 10A 230V 6SCH1C13 10370054 Register free see stock
Ingram Micro EASY PDU EPDU1010B-SCH BASIC 1U CA61740
TD Synnex UK APC Easy Basic Rack PDU EPDU1010B-SCH - Power distribution unit (rack-mountable) - AC 200-240 V - 1-phase - input: IEC 60320 C14 10A - output connectors: 7 (IEC C14, 6 x CEE 7/4) - 1U - 19" - 2.5 m cord 6326487
Westcoast/Data Select EASY RACK PDU BASIC 1U 1 PHASE 2.3KW EPDU1010B-SCH
ECPROF Listwa zasilaj-?ca EPDU1010 Easy PDU Basic 1U 10A 6SCH 1C13 230V EPDU1010B-SCH
EET Easy PDU EPDU1010B-SCH Basic EPDU1010B-SCH
Ingram Micro CS EASY PDU EPDU1010B-SCH BASIC 1U CA61740
Memory Bank EASY RACK PDU BASIC 1U 1 PHASE 2.3KW CLEPDU1010B-SCH
SYNAXON Easy Basic Rack PDU EPDU1010B-SCH - power distribution unit STD10106832

Retail Prices

Merchant Product Condition Updated Price
Amazon New £136.43

Related Products

Description

It’s an Easy rack PDU basic model to be placed horizontally (19” rack-mountable) with 230VAC as nominal voltage Its input circuit is 10A with one C13 and six SCHUKO output receptacles The input cord length is 2.5m The housing material is aluminum extrusion Its operating condition is from -5˚C to +45 ˚C, 5-95% RH non-condensing You can use four M6x16mm screws and four M6 cage nut for the rack mounting brackets It has CE certification with one year warranty

Specifications

Design
On/off switchNo
TypeSingle-phase
PDU typesBasic
MountingHorizontal
Product colourBlack
Rack capacity1U
Housing materialAluminium
Ports & interfaces
AC outlets quantity7 AC outlet(s)
AC outlet typesC13 coupler, Type F
Power plugC14 coupler
Features
Cable length2.5 m
Ergonomics
Cable length2.5 m
Power
Maximum power2300 W
Nominal input voltage230 V
Maximum current10 A
Weight & dimensions
Weight600 g
Width482 mm
Depth44.4 mm
Height44.4 mm
